MiniFlex XpC
Compact X-ray diffractometer
Designed for automated workflows
In a move to bring lab-quality performance to the manufacturing floor or laboratory automation for autonomous experiments, Rigaku introduces the MiniFlex XpC. A benchtop or floor-standing version is available, depending on the purpose. The MiniFlex XpC provides flexibility for a wide range of laboratory and automated production environments. The EasyX control software makes the MiniFlex XpC easy to operate, requiring minimal clicks to run. This simple interface means there will be no accidental variance from operator to operator.
The MiniFlex XpC can be configured with a conveyor belt or robot for automated sample processing and integration with other instruments and automation/autonomous systems; it can thus greatly improve throughput.
Supported by LabLinc Studio
MiniFlex XpC Overview
Sample loading mechanism
The optimal loading mechanism allows samples to be added without opening the instrument door. An eight-position sample changer is included as standard, and up to 24 samples can be handled when combined with the optional transfer robot.
Highly durable and highly accurate horizontal goniometer suitable for quality control
Using the technology cultivated with SmartLab, we have developed a new, durable, compact horizontal sample goniometer that is optimal for quality control.
Compact, high-output X-ray generator
The MiniFlex XpC features a compact molded ceramic X-ray tube. The generator for the X-ray source has also been improved, enabling a high output of 800 W while being almost the same size as the 600 W generator of the MiniFlex desktop X-ray diffractometer.
Selectable detectors based on the application
The MiniFlex XpC offers a choice of advanced detectors. The D/teX Ultra250 maximizes throughput with its wide detection area for faster measurements. The XSPA-200 ER delivers superior energy resolution for low-background, high signal-to-noise ratio data, making it ideal for challenging samples containing transition metals.
EasyX software for screening and quality control
Simple measurement, automatic analysis, display of results, and pass/fail judgment are possible with this software, so even those who are unfamiliar with analysis can use it with confidence. In addition, the trend graph creation function makes it possible to visualize the results and tangible changes in the device status.
Automation support
The MiniFlex XpC can be connected to automation equipment by combining with a robot arm or a conveyor belt (both optional). Industry standard sample holders (steel rings) are supported as standard. This apparatus achieves the world’s smallest footprint for an online diffractometer (approx. 1 m²).
LabLinc Studio compatible
Compatibility with LabLinc Studio, Rigaku's modular platform for autonomous laboratories, allows the MiniFlex XpC to be integrated into automated systems and autonomous laboratory workflows.
MiniFlex XpC Features
Rigaku provides X-ray diffractometers for quality control developed using the X-ray diffractometer technology cultivated for research and development over many years. It is easy for anyone to use and stable analysis results can be obtained regardless of the operator, so there is no difference in the results between operators. Work efficiency can be improved using the sample loading mechanism and D/teX Ultra250 detector.
- Touch panel operation
- Runs within 3 taps from measurement to data analysis
- Based on SmartLab Studio II
- Languages: Japanese, English, Chinese
MiniFlex XpC Videos
MiniFlex XpC Specifications
| Technique | X-ray diffraction (XRD) | |
|---|---|---|
| Application benefit | Compact X-ray diffractometer for quality control | |
| Technology | θ-θ X-ray diffractometer for automated workflows | |
| Attributes | Compact X-ray generator Compact horizontal goniometer D/teX Ultra250, XSPA-200 ER detectors Sample loading mechanism |
|
| Computer | Windows® 11 IoT Enterprise (external PC configuration also available) |
|
| Dimensions | Benchtop model: 700 mm (W) × 840 mm (D) × 925 mm (H) Floor-standing model: 700 mm (W) × 840 mm (D) × 1690 mm (H) |
|
| Mass | Benchtop model: 230 kg Floor-standing model: 310 kg |
|
| Power requirements | Single-phase, AC 200–230 V ±10%, 50/60 Hz ±1%, 7.0 A | |
MiniFlex XpC Application Notes
The following application notes are relevant to this product
-
B-XRD1165 - Phase Identification and Quantitative Analysis of Iron Ore by X-ray Diffraction
-
BATT1003 - Management of Graphitization Degree for Graphite Anode Material
-
BATT1002 - Lattice Constant and Crystallite Diameter Management for NCM Cathode Material
-
XRD1161 - MiniFlex XpC for Clinker Application
-
XRD1160 - Fast Analysis of Mineralogical Phases in Blended Cements using Miniflex XpC
-
B-XRD1148 - Composition ratio classification of ternary cathode material by cluster analysis
-
B-XRD1150 - Evaluation of Graphitization Degree of Lithium-ion Battery Carbon Anode Material by X-ray Diffractometry
