Determining the Constituents of Concrete and Resolving Complex Mixtures into Individual Constituents using XRF Analysis
This is a written summary of a live webinar presented on September 25, 2024. The recording and resources are available on the recording page.
Presented by:
Webinar summary
The webinar offers a comprehensive introduction to the use of wavelength dispersive X-ray fluorescence (WDXRF) for analyzing the constituents of concrete and resolving complex mixtures, specifically tailored for professionals in the cement and construction industries, as well as R&D and quality control labs. Carmen explains the relevance of WDXRF in modern concrete analysis, especially in response to quality issues, durability concerns, and evolving environmental regulations. She introduces key Rigaku WDXRF instruments such as the ZSX Primus series, which include sequential and simultaneous models suited for both high-precision laboratory environments and high-throughput industrial settings.
The central focus is on the need for reliable methods to determine the exact composition of concrete, especially when investigating failures or validating mix designs. Carmen highlights the importance of sampling quality due to the inherently inhomogeneous nature of concrete. Accurate results depend on careful sample preparation, including drying, physical separation of aggregates, and pulverization, followed by chemical analysis using the fusion method. The fusion technique involves mixing the sample with a flux and creating a homogenous glass bead that eliminates the matrix effects and mineralogical variations that typically plague pressed powder methods. This allows for significantly improved accuracy and repeatability, especially when measuring oxides and other elemental components critical to cement performance.
Carmen explains how Rigaku’s software can resolve complex mixtures using simultaneous equations that process the elemental data obtained from the WDXRF instrument. By inputting the chemical signatures of each constituent material and the finished concrete, the software can determine the original proportions of materials used. This is invaluable in quality assurance and customer support when validating whether the supplied mix design was followed or if deviations have caused performance issues. The method is validated through case studies where concrete samples were physically and chemically analyzed, and then compared to lab-produced control cubes, with results demonstrating high accuracy and repeatability.
Carmen breaks down key benefits of XRF, such as its compliance with international standards like EN 196-2, the elimination of daily calibrations, low operating costs, and ease of use for non-experts. She elaborates on Rigaku’s instrumental features like the rhodium X-ray tube positioned above the sample to avoid dust contamination, dual vacuum systems for better sensitivity to light elements, and advanced crystal configurations for separating overlapping spectral lines. These hardware elements, combined with robust software and calibration protocols based on certified reference materials, ensure that users can obtain consistent, precise results over time.
Carmen addresses concerns about analyzing aged or unknown concrete, reinforcing that accurate analysis requires knowledge of the original mix constituents. While WDXRF offers exceptional capabilities for routine and advanced analysis of fresh or known samples, its effectiveness depends on proper sample documentation and handling.
Overall, the webinar presents WDXRF as a powerful, practical, and scalable analytical solution for professionals seeking to improve quality control, meet environmental targets through the use of blended cements, and resolve complex material issues in cement and concrete applications.
Key questions answered in the webinar:
-
XRF (X-ray fluorescence) is an analytical technique used to determine the elemental composition of materials. In concrete analysis, Rigaku's WDXRF instruments (like the ZSX Primus series or Supermini200) are used to chemically analyze concrete and its raw materials (cement, aggregates, sand, fly ash, etc.). This involves preparing samples using a "fusion method" where the material is dissolved in a flux to create a uniform glass bead. This fused bead is then analyzed by the XRF instrument, providing highly accurate and precise elemental data that can be used to resolve the original mix design.
-
The fusion method offers several significant benefits for concrete analysis. It effectively reduces matrix effects (interferences from other elements in the sample) due to dilution, eliminates errors caused by sample inhomogeneity, and removes mineralogical effects (where different forms of the same element might produce varying signals). This ensures that all elements in the sample are measured consistently and accurately, leading to more reliable calibration curves and results compared to other methods like pressed powder analysis, which can be affected by particle size and mineralogy.
-
Rigaku provides specialized software for "mixed resolution" that uses simultaneous equations. This software takes the chemical analysis data (obtained via XRF and the fusion method) of the final concrete product and its individual constituents (cement, various sands, aggregates, fly ash, etc.). By solving these simultaneous equations, the software can determine the precise proportion of each constituent in the concrete mixture. The software also includes a "goodness of fit" verification option to assess the accuracy of the resolution, aiding chemists in validating their results.
-
Sample preparation for concrete analysis is meticulous to ensure accuracy. It involves:
- Sampling: Taking a sufficiently large and representative sample (e.g., 20 kg for concrete, 7 kg for cement) due to the material's inhomogeneity.
- Documentation: Photographing the concrete sample before and after cutting.
- Physical separation: Drying the concrete, heating it in a furnace (around 600°C overnight) to induce cracking, submerging it in cold water to aid separation, and then physically separating and screening the different aggregate sizes (e.g., 13mm, 26mm stones) using a hammer and sieves. These physically separated components are also chemically analyzed for verification.
- Chemical preparation: Drying, jaw crushing (for concrete), splitting, pulverizing, and finely milling all individual materials (constituents and the concrete itself) to obtain a representative analytical sample. This material is then oxidized (ignited) to remove volatile components, mixed with a flux, and fused into a uniform glass bead for XRF measurement.
-
Verification is a crucial part of the method. After chemically analyzing all constituents and the concrete sample, a "control cube" is prepared in the laboratory following the customer's known mix design using the submitted constituents. The chemical analysis of this control cube is then compared to the results obtained from the mixed resolution software. A close match between the calculated proportions and the known mix design of the control cube validates the accuracy and reliability of the entire analytical process. Precision is demonstrated through triplicate analyses of all materials, showing highly repeatable results.
-
Analyzing old concrete samples (e.g., from old structures with damage) using this method is tricky because it relies heavily on having the exact original constituents (cement type, specific aggregates, sands) that were used to make the concrete. If the original mix design and constituent materials are unknown or unavailable, it becomes difficult to accurately resolve the mixture using the simultaneous equations approach presented. While other analytical methods might exist, this specific "mixed resolution" technique requires precise knowledge of the starting materials for accurate results.
-
Rigaku's ZSX Primus IV WDXRF instrument offers several advantages:
- X-ray tube above sample: This design ensures long-term X-ray tube usage and prevents dust contamination, contributing to high reliability and low cost of ownership.
- Thin beryllium window: Provides excellent light element detection (e.g., Ca, Mg) with higher intensity (>40% compared to competitors), leading to better sensitivity, lower detection limits, and faster analysis times.
- Automatic pressure control: Maintains a stable and consistent vacuum, improving accuracy and precision, especially for elements with low fluorescent yields like boron or fluorine.
- Reproducible sample positioning: Ensures consistent measurement conditions.
- Advanced analyzing crystals: Features like curved germanium and PET crystals offer higher sensitivity, while synthetic crystals like RX26 and RX35 provide optimized resolution for specific element overlaps.
- User-friendly software: Simplifies quantitative method setup with built-in expertise, making it accessible for both experts and non-experts.
- Robustness and reliability: Designed as industrial units with strong application and service support.
