Three-dimensional modeling for complex structures based on small-angle X-ray scattering

Three-dimensional SAXS modeling reconstructs the internal nanostructure of a material without requiring destructive sample preparation. Unlike TEM or SEM, which examine thin sections or surfaces and may alter fragile materials during preparation, SAXS probes the bulk structure through X-ray penetration. This makes it especially valuable for delicate porous materials such as aerogels, polymers, and catalyst supports while also providing quantitative structural information throughout the sample volume.

Reverse Monte Carlo (RMC) modeling begins with an initial structural model and repeatedly adjusts particle positions while comparing simulated scattering patterns to experimental SAXS measurements. Each change is accepted only if it improves agreement with the measured data. Through many iterations, the model converges toward a realistic three-dimensional representation of the material that reproduces the observed scattering behavior.

The conventional Debye scattering equation produces artificial oscillations at low scattering angles when calculations are performed within finite simulation cells. The modified equation extends the treatment of particle correlations beyond the simulation cell using an analytical approximation of the surrounding material. This significantly reduces finite-size artifacts, allowing accurate modeling with practical computation times on standard computers instead of requiring supercomputers.

After generating the three-dimensional particle arrangement, image analysis techniques such as distance mapping and local thickness transformations are applied to the reconstructed volume. These methods identify the largest spheres that fit within the pore network and calculate a quantitative pore size distribution throughout the material. The approach produces a detailed three-dimensional description of pore geometry rather than simply estimating average pore sizes.

The reconstructed pore size distributions closely match results obtained from transmission electron microscopy and nitrogen gas adsorption measurements. Median pore diameters determined by the different methods are in good agreement, demonstrating that the SAXS-based structural model accurately represents the material's internal architecture. Differences primarily arise because electron microscopy analyzes limited regions and gas adsorption cannot measure closed pores.

Gas adsorption only measures pores that are connected to the external surface and accessible to the adsorbing gas. Closed or isolated pores do not contribute to the measured adsorption, causing the total pore volume to be underestimated. Three-dimensional structural modeling from SAXS data can identify both open and closed pores, providing a more complete picture of the internal pore network.

The method is well suited for hierarchical nanostructured materials composed of aggregated nanoparticles, including silica aerogels, catalyst supports, polymer composites, rubber materials, ceramics, and other porous functional materials. It is particularly valuable for systems where preserving the original internal structure is important and destructive imaging techniques are impractical or may alter the sample.
