Introduction to Powder X-ray Diffractometry I: Overview

Powder XRD can do much more than identify compounds. It can quantify phase amounts, estimate the ratio of crystalline to amorphous material, evaluate crystallite size and lattice strain, refine crystal structures by methods such as Rietveld analysis, perform in-situ measurements under changing conditions, analyze preferred orientation, measure residual stress, and support PDF analysis for local atomic arrangements. It can also be used for particle or pore size analysis through small-angle scattering-related methods.

Materials with the same chemical composition can still have different crystal structures, and crystal structure determines the diffraction pattern. Diamond and graphite are both carbon, and rutile and anatase are both TiO2, but their atomic arrangements differ. Because diffraction peak positions and intensities depend on the lattice spacing and atomic arrangement, their patterns are different enough to tell them apart.

The method is non-destructive, so the sample can often be used again for other analyses. It can usually be done in air, which makes sample preparation straightforward. It also gives average information over the irradiated part of the sample rather than only a tiny local spot, which is useful when you want a representative picture of the material. These features make powder XRD practical for a wide range of industrial and research applications.

A typical diffractometer has an X-ray generator on the incident side, a goniometer that controls the geometry between source, sample, and detector, and a detector on the receiving side. Many modern systems keep the sample horizontal, which helps when measuring powders, liquids, gels, or bulk samples that are difficult to hold securely. The system can also accept attachments that expand its measurement capabilities for specialized studies.

A 0D detector records intensity at one position at a time and typically needs a receiving slit to get proper angular resolution. A 1D detector has many strip-shaped sensing elements, so it can collect data across a range more efficiently and usually gives much higher intensity than 0D measurement while preserving high angular resolution. A 2D detector uses a matrix of pixels and captures a much wider portion of the diffraction pattern, which helps reveal Debye rings directly and makes sample features like preferred orientation or coarse grain effects easier to see.

The optics determine how the X-ray beam reaches the sample and strongly affect data quality. Different beam configurations such as parallel, divergent, and convergent beams are suited to different purposes. Parallel beam optics can be used for both reflection and transmission measurements, divergent beams are mainly used in reflection, and convergent beams are used in transmission. Matching the radiation and optics to the measurement goal is important for collecting high-quality data.

1D detection provides a strong balance of speed, intensity, and resolution. Because the detector already contains positional information in the 2-theta direction, it does not need the same slit-based limitation used in 0D systems. That leads to much higher collected intensity, often tens of times greater in principle, while maintaining a narrow effective peak width. For routine powder diffraction, this makes 1D systems especially efficient and practical.

Not always. Quantitative analysis is most reliable when multiple phases are present in a powdered sample, because the material is more uniformly represented in the irradiated volume. Bulk samples can also be quantified if the phases are distributed uniformly within the X-ray penetration depth. However, if the sample has a layered structure, phases nearer the surface can appear overrepresented because of X-ray absorption effects. In bulk materials, texture and residual stress are often especially important evaluation targets.
