XRF Standards: What to Use, When, and Why

Have you ever wondered why testing the same material in different labs sometimes gives slightly different results? The answer usually comes down to standards. Choosing the right standards and knowing when to make your own determines whether your XRF results are reliable, comparable, and trustworthy.

Below, we’ll walk through the science behind XRF standards in simple terms, explain the “tricks” materials can play on measurements, and share practical tips for keeping your instrument honest.

What are XRF standards, and why do scientists rely on them to get accurate results?

XRF machines don’t measure how much of an element is present directly—they measure X-ray intensities. To turn those signals into accurate elemental concentrations, scientists use standards, which are materials with known compositions.

Standards act like a “ruler” for your XRF machine. Without them, the readings are just numbers, not meaningful composition. Using proper standards ensures results are traceable, comparable across labs, and defensible.

Further reading:

• Potts, P.J. & Webb, P.C. (1992), X-ray fluorescence spectrometry, Journal of Geochemical Exploration 44(1-3): 251-296.
• Jenkins, R., Gould, R.W. & Gedcke, D. (1995), Quantitative X-ray Spectrometry,(2nd ed.).

Why does an element with identical composition show different results in different samples?

Even if an element is present in identical composition, the XRF reading can vary depending on the matrix and the rest of the material surrounding the element. Surrounding material/elements absorb X-rays or even enhance the signal from other elements.

This is why two identical-looking samples can give different numbers unless the standard matches the sample type (matrix).

Further reading:

• Rousseau, R. M. (2001), Detection limit and estimate of uncertainty of analytical XRF results, Rigaku Journal, 18(2), 33-47.

How do materials “trick” the XRF machine into reading too high or too low?

XRF machines measure elements by detecting the X-rays they give off. But sometimes, the surrounding material—the “matrix” changes the fluorescence signal, making the readings too high or too low. This happens in two main ways:

1. Absorption (making an element look smaller): Some atoms in the sample can absorb the fluorescence X-rays from the element you’re measuring. This makes that element appear less abundant than it really is.

Example: When measuring S in coal, Fe can absorb some of sulfur’s X-rays, so S seems lower than it actually is.

2. Enhancement (making an element look bigger): Some atoms can give off X-rays that excite nearby elements, boosting their signal. This makes those elements appear more abundant than they really are.

Example: In steel, Fe can excite Cr, so Cr readings are artificially higher.

Further reading:

• Rousseau, R.M. (2006), Corrections for matrix effects in X-ray fluorescence analysis—A tutorial, Spectrochimica Acta B 61(7):759-777.
• Beckhoff, B. (2006), Handbook of Practical X-ray Fluorescence Analysis.

Why does matching your standard (matrix–matched) to the sample make a big difference?

Using matrix-matched standards means your standard is the same material and has a similar composition to the sample. This automatically corrects for absorption and enhancement effects, giving reproducible results across different labs.

A classic example is soil testing. Calibrating with pure oxides fails because real soils contain moisture and organics that affect X-ray absorption differently. Matrix-matched standards solve this mismatch.

Further reading:

• Maame, E.T. (2020), Optimizing Sample Preparation and Calibrations in EDXRF for Quantitative Soil Analysis, Agronomy, 10(9), 1309 .

How do scientists decide to choose right calibration approach?

Whether and how standards are used depends on the calibration method. Let’s think about how to choose the right one. There’s no single “best” calibration strategy because the best choice depends on your needs and what is available.

• Empirical calibration is ideal when good standards exist. It directly compensates for matrix effects and is suitable for routine applications such as cement or glass.
• The fundamental parameters (FP) method can be useful when you cannot obtain standards or when your materials vary widely, such as soils environmental dust or residues.
• Many labs use a hybrid approach: FP for flexibility, then verify against empirical standards for accuracy.

Further reading:

• Rousseau, R.M. (2006), Corrections for matrix effects in X-ray fluorescence analysis—A tutorial, Spectrochimica Acta B 61(7):759-777.
• Jenkins, R. (1999), X-ray Fluorescence Spectrometry.
• Rigaku Corporation (2023/2024) Application Note: Standardless FP Analysis of Plant, Animal and Food Samples Applying Correction by Scattering Line.

Does the way you prepare a sample – like pressing it or melting it – change the results?

Yes! Sample preparation is critical to optimize sensitivity and reduce sample variations:

• Pressed pellets: Fast and cheap, but sensitive to grain size, mineralogy, and pressure variations.
• Fused beads: Melting the sample into glass removes grain size and mineralogical effects entirely, giving more accurate results for complex materials like cement or ores.

Even with perfect calibration, using the wrong sample form can introduce bias.

Further reading:

• Potts, P.J. & Webb, P.C. (1992), X-ray fluorescence spectrometry, Journal of Geochemical Exploration 44(1-3): 251-296.
• Vanhoof, C., (2023), Atomic spectrometry update – a review of advances in X‑ray fluorescence spectrometry and its special applications, Journal of Analytical Atomic Spectrometry, 38, 1730‑1743.

What is Compton normalization, and when does it help make reading more reliable?

Even well-prepared pellets can differ in density or height. Compton normalization is especially useful for pressed powder pellets where preparation can vary. This correction method uses the Compton scatter peak—a signal created when tube X-rays scatter off the sample’s electrons. This peak is sensitive to the sample’s density and composition.

By comparing the analyte’s intensity to the Compton peak intensity, analysts can normalize measurements to account for differences in sample packing, particle size, or matrix variations.

Further reading:

• Rousseau, R.M. (2006) Corrections for matrix effects in X-ray fluorescence analysis—A tutorial, Spectrochimica Acta B 61(7):759-777.

What’s the difference between commercial reference standards and one’s labs make themselves?

• CRMs (Certified Reference Materials): Reference materials accompanied by a certificate that states the certified values, associated uncertainty, and metrological traceability. These are used to ensure accurate and traceable measurements.
• RMs (Reference Materials): Materials that are suitable for measurement use but do not necessarily have certified values with defined traceability. In practice, in-house RMs may be prepared when no suitable commercial materials are available.

Mining and catalyst labs often deal with uncommon or highly specialized sample matrices for which no commercial standards exist, making custom RMs necessary for accurate measurement and ongoing quality assurance.

How many standards do you really need to trust your XRF measurements?

Technically, the number of standards needed is the number of elements in the sample squared. Practically, a more useful guideline is the number of elements in the sample plus four. The number of standards is based on the number of elements to ensure there enough degrees of freedom to use correction factors to compensate for matrix absorption and enhancement effects, as well as optimize accuracy for both linear and non-linear responses.

As you can see, it can take large number of standards to calibrate for a complex multi-element material like soil or fly ash, and so the fundamental parameters approach in XRF is an excellent alternative requiring few standards.

How do scientists make sure their XRF machine stays accurate day after day?

Even the best calibration drifts over time. Regular QC checks are essential:

• Daily: Run one matrix-matched check standard. Confirm results within ±2σ.
• Weekly: Run several standards and track trends with charts.

Small shifts over time are more dangerous than occasional outliers, so consistent monitoring is key.

Further reading:

• Rousseau, R. M. (2001). Detection limit and estimate of uncertainty of analytical XRF results, Rigaku Journal, 18(2), 33-47.
• Rigaku Corporation (2023/2024) Application Note: Standardless FP Analysis of Plant, Animal and Food Samples Applying Correction by Scattering Line.

When is XRF enough, and when should a sample be sent to another technique like ICP?

ICP is better for ultratrace detection and can measure extremely low concentrations—down to sub-ppm or even ppb levels. ICP is preferred when maximum sensitivity is required.

XRF is fast, non-destructive, economic, and works especially well for solid, mineral-based, or metal samples such as ores, cements, alloys, and catalysts, where traces to major concentrations and bulk composition are the focus.

Why this matters: Understanding the strengths and limits of each technique helps labs choose the right tool. ICP when accuracy at very low levels is critical, and XRF when speed, cost, and convenience are more important.
