TMA8311/HUM

Humidity Controlled TMA

Measurement of mechanical property change with respect to temperature and humidity

TMA/HUM is an instrument where TMA measurements can be carried out in a water vapor atmosphere with a constant relative humidity. In TMA/HUM, TMA is measured at a constant water vapor partial pressure providing a complete understanding of the sample’s expansion or shrinkage with regards to different water vapor partial pressure.

Get a Quote Ask a Question

TMA8311/HUM Overview

Especially during sintering of ceramics in a water vapor atmosphere, the actual sintering conditions can be carried out in a laboratory-based environment.

Here TMA measurements held at a constant temperature while changing the relative humidity measure the swelling ratio with regards to relative humidity effective for the sample’s swelling property evaluation.

The humidity generator (HUM-1) uses N₂ base gas to create a water vapor containing a humidity controlled gas to be introduced to the TMA.

Here, the TMA is equipped with a specialized electric furnace that keeps the temperature constant thru a circulator to prevent condensation even at high water vapor concentration atmosphere and can perform measurements at a maximum of 85℃ 90% RH atmosphere. The humidity sensor equipped with a feedback control leads to a stable humidity for longer measurements. Since the relative humidity settings in TMA is integrated in the temperature program, the user can change the relative humidity in each step of the temperature program.

TMA8311/HUM Features

Humidity control

High-sensitivity, high-precision measurement by the differential method

Multi-measurement system that excels in expandability

Flexible handling of various sample sizes

Notable enhancement of heating and cooling rates enabled by a compact electric furnace

Simple sample setting mechanism, the first of its kind in differential TMA

Different measurement methods

Compression loading method
Tensile loading method
Penetration method
Differential penetration method
3-point bending method
Single rod compression loading method

Measuring temp. range

Standard model: Ambient to 1100°C
High-temperature model: Ambient to 1500°C

Safety foremost emphasized on the entire system

TMA8311/HUM Specifications

Technique	Humidity controlled thermomechanical analyzer
Benefit	Measurement of a mechanical property change with respect to temperature and humidity
Technology	Differential expansion principle where the thermal expansion or shrinkage generated from the detection mechanism itself can be canceled
Attributes	Multi-measurement system that excels in expandability
Options	High-temperature model: Ambient to 1500°C
Computer	External PC
Dimensions	380 (W) x 580 (H) x 580 (D) (mm)
Mass	30 kg (core unit)
Power requirements	1Ø, AC100-120V/200-240V 50/60Hz 15A
