PhotonJetMAX-S
Double the diffracted intensity, same operating costs
| Now available in copper and molybdenum |
Maximizing the number of photons hitting your detector can make all the difference, whether you're clearing a backlog of samples or extracting data from a challenging one. The PhotonJetMAX-S, our latest microfocus sealed tube source for the XtaLAB Synergy-S, delivers more than twice the diffracted intensity while maintaining the versatility to handle a wide range of samples.
When designing the PhotonJetMAX-S, our goal was to enhance performance without increasing operating costs. The PhotonJetMAX-S uses the same tube technology as the PhotonJet-S, ensuring that when a replacement tube is needed, the cost remains the same. Additionally, it operates at the same power level as the PhotonJet-S, making it equally eco-friendly.
PhotonJetMAX-S Overview
Enhanced performance
The PhotonJetMAX-S leverages Rigaku Innovative Technologies (RIT) optic technology to maximize photon capture from the tube and focus them onto the sample. Compared to the PhotonJet-S, it delivers over two times more photons to the detector.
Superior stability
Performance and stability go hand in hand. That's why the PhotonJetMAX-S is equipped with our water-to-air cooling approach. Our water-to-air cooling system uses water only where it’s necessary—in a closed, low-pressure circuit—to allow precise control of the source temperature and flux yet ensure reliability. Additionally, water efficiently removes heat from the cabinet eliminating the source as a cause of air turbulence and heat near the sample.
Proven reliability
Built with our long-life tube technology, the PhotonJetMAX-S is designed to keep running sample after sample for years, giving consistent performance and reliability.
Low operating costs
Operating the PhotonJetMAX-S won't break the bank. It uses the same tube technology as the PhotonJet-S, so replacement tubes are no more expensive. Plus, its low operating power keeps energy consumption—and your costs—down.
Eco-friendly design
The PhotonJetMAX-S achieves peak performance at just 50 W, making it the most energy-efficient, high-performance microfocus sealed tube system available.
By choosing the PhotonJetMAX-S, you’re enabling the analysis of smaller samples or increasing throughput as needed. With our patented divergence slits included as standard, you can confidently tackle any sample type, whether it has a large or small unit cell, is a single-crystal or powder, or is a twinned sample.
PhotonJetMAX-S Features
- More than 2 times diffracted intensity
- Patented divergence slit mechanism as standard
- 106 micron beam optimized for smaller samples
- Faster experiments
- Better data quality
- No increase in operating costs
