Xsight Micron FC

Compact Two-Dimensional SCMOS And CCD Detector

X-ray and EUV detector

Rigaku XSight Micron FC (fiber-coupled) is an ideal compact two dimensional (2D) X-ray CCD or sCMOS camera optimized for use in micron applications such as X-ray tomography and metrology.

XSight Micron FC Compact two-dimensional CCD detector XSight Micron FC Compact two-dimensional sCMOs detector

Xsight Micron FC Overview

The XSight Micron FC camera has a robust body preventing any scattered X-rays from hitting the CCD or sCMOS sensor directly and thus raising noise. The camera can be easily mounted via M6 threads on the bottom of the camera body. The XSight Micron FC camera is a one package instrument. Data from the camera are transferred via high speed USB2.0. No additional electronics box, special computer board or water chiller is necessary. Just plug USB2.0 cable into your computer and start taking images! Intuitive software offers all basic tools.

Applications

  • X-ray microscopy
  • X-ray topography
  • X-ray optics adjustment & metrology
  • X-ray imaging

Technical features

Nominal Field of view Model FC 5400 18.0 mm (H) x 13.5 mm (V)
Model FC 2160 7.2 mm (H) x 5.4 mm (V)
Nominal effective pixel size Model FC 5400 5.40 µm
Model FC 2160 2.16 µm
Typical spatial resolution (FWHM) Model FC 5400 16 µm (@ 8 keV)
Model FC 2160 8 µm (@ 8 keV)
Spectral range 5 keV – 30 keV
Typical dynamic range 3100 : 1 (70dB)
Typical acquisition gain 0.45 e-/ADU
Typical readout noise 10 e- rms
Readout rate 8 Mpix/s (approx. 1 frame per second)
Typical dark current 0.02 e-/pix/∙s @ -30°C
Binning independent binning in x, y
Remote triggering input / output trigger
Data interface USB 2.0

Xsight Micron FC Features

Field of view
13.3 (H) x 13.3 (V) sCMOS
18 (H) x 13 (V) CCD
Spectral range
3 keV – 30 keV
Dynamic range
20000 : 1 sCMOS
3100 : 1 CCD
Acquisition gain
0.45 e-/ADU CCD
Readout noise
1.5 e- rms sCMOS
10 e- rms CCD
Readout rate
approx. 100 fps sCMOS
1 fps CCD
Cooling temperature stability
0.1°C
Dark current
0.5 e-/pix./s sCMOS
0.03 e-/pix./s CCD
Binning
Independent binning in x, y
Remote triggering
Input / output trigger
Data interface
USB2.0

Xsight Micron FC Videos

Xsight Micron FC Specifications

Technique Compact two-dimensional sCMOs and CCD detector
Benefit Micron resolution, large FOV
Technology Fiber coupled scintillator to sCMOS or CCD camera
Applications X-ray tomography and metrology applications, semicondutor metrology
Options Large field of view, fast readout
Dimensions 80 mm (V) x 80 mm (H)
Mass 1 - 2 kg
